Curved surface heat transfer machine

Curved surface heat transfer machine

1- Meaning of curved surface heat transfer machine
Curved surface heat transfer machine is a new type of printing machine that heats and pressurizes the pre-printed heat transfer film to the curved surface product. It has high production efficiency and significant economic benefits. It is an ideal equipment for the surface printing and processing industry. It can be used for hot stamping on the curved surface of plastic, wood, metal, leather, glass and other products.

2- Circuit principle of curved surface heat transfer machine
From the circuit principle, the curved surface heat transfer machine is a temperature controller and a time controller that jointly control an electric heating device. The temperature and time can be preset. The temperature of the electric heating device is stable at the set value, and the time will automatically disconnect the power supply after reaching the set value. The heating element of the curved surface heat transfer machine is made into a cylindrical shape according to the curved surface product to be transferred.

3- Functional characteristics of curved surface heat transfer machine

1. Curved surface heat transfer machine electronic IC integrated controller multi-function program. Flat ironing, rolling ironing, heat transfer, hot stamping, hot stamping, hot stamping and hot stamping stroke can be selected.

2. Special cylinder, strong and stable pressure, up to 250kg/f, oil pressure connection 380V, oil pressure shuttle and drop, up to 1 ton.

3. The hot stamping pressure, temperature and hot stamping time of the curved heat transfer machine are adjustable.

4. The workbench can be customized to move forward and backward automatically, which is convenient for safe and fast operation.

5. The speed and pressure of the workbench are adjustable, and the time is adjustable.

6. The automatic film collection is adjustable. Using Taiwan motor, it can be customized to be more accurate in variable speed film collection, and the film moving accuracy is within 0.5mm.

7. The curved heat transfer machine is equipped with a photoelectric tube (Taiwan Yangming electric eye, 250 high-precision movements per second) to accurately track and control the heat transfer film with positioning points.

8. The height of the hot stamping head can be adjusted, and it can stamp larger 300MM workpieces. All screws are grade 12.9, which is more stable and durable.

9. Equipped with emergency stop safety protection device to ensure the safety of the operator.

The curved surface heat transfer machine designed and produced by our company is a new series of machines designed and manufactured for users with many years of production experience and the strengths of various companies. The machine parts adopt standardized design, and all mechanical parts are processed by process to improve wear resistance. Key components are made of reliable imported components, which improves the stability and service life of the whole machine.
