A brief introduction to the conical heat transfer machine

1- A brief introduction to the conical heat transfer machine
The conical heat transfer machine is a heat transfer machine specially designed for conical products. This type of heat transfer machine uses a clamp to fix the conical substrate. The operator then adjusts the various parameters of the machine according to the taper of the substrate, keeps the horizontal surface of the substrate parallel to the silicone plate surface under the rubber roller, and then starts the printing switch to accurately press the heat transfer film onto the surface of the substrate.

It is worth noting that not all conical products can be directly put on the machine. If the product taper is too large, it is recommended to use a hand bag to complete the transfer.
heat transfer machine
2- The circuit principle of the conical heat transfer machine
HD-825 conical profile water cup

For example, the HD-825 conical heat transfer machine, from the circuit principle, is an electric heating device controlled by a temperature controller and a time controller. The temperature and time can be set in advance. The temperature of the electric heating device is stable at the set value, and the time will automatically disconnect the power supply after reaching the set value.

3-Five operating steps of conical heat transfer machine
1. Inspection

Any machine needs to be simply checked before formal operation, and the conical heat transfer machine is no exception.

2. Turn on the power

Turn on the power switch and check whether the power indicator light turns on; if the indicator light does not light up, return to the plug to check whether it is loose.

3. Adjust the machine

Adjust the machine according to the product to be transferred, first install the product fixture, place the product on the fixture, and adjust the rubber roller to a suitable distance from the product; then install the flower film on the machine, and level the distance between the flower film and the printing surface, generally within 1mm-4mm.

4. Adjust the temperature

Turn on the electric heating switch, adjust the thermostat to 100℃, let the rubber roller preheat, wait until the temperature stabilizes at 100℃, and then slowly adjust the set temperature to the hot stamping temperature suitable for the workpiece;

5. Start hot stamping

Next, step on the foot switch to complete a hot stamping cycle, observe the hot stamping situation and adjust it until the hot stamping achieves the ideal effect.

4-Which products are suitable for the conical heat transfer machine?
heat transfer film for painted metal
Conical heat transfer is suitable for products with a taper on the surface, which can be divided into three categories according to the current application type.

1. Cup

Most cups are in the shape of A, and the printing materials are diverse, such as plastic (ABS, PP, PC, PE, etc.), metal, glass, etc.

2. Lampshade

The lampshade is an indispensable item for interior decoration. Its shape is narrow at the top and wide at the bottom, presenting a ladder-like shape. Due to the large taper of the lampshade, it is generally used in the form of a hand bag to complete the transfer.

3. Trash can

When the conical surface of the trash can is thermally transferred, the pattern of the trash can is fan-shaped when it is spread out, and the pattern needs to be connected from beginning to end. This requires experienced operators to adjust the trash can and the conical thermal transfer machine first to ensure that the pattern at the beginning and end has a natural transition at the overlap.

-------------------

1 Matters needing attention in packaging and transportation of thermal transfer film
The production process of thermal transfer film has many links, which can be roughly divided into the following six: select the appropriate base film → apply release → print on the machine → apply glue → re-inspection → slitting → packaging and transportation, and then it can reach the hands of customers. In actual production, there are always some small problems. If these small problems are not solved in time, they will bring fatal defects to product quality, and packaging and transportation are the last link in the production of thermal transfer film.

Matters needing attention in packaging and transportation of thermal transfer film

If there are some small problems in the last link, it will be a bit of a loss. It will not only cause economic losses, but also delay delivery time, leave a bad impression on customers, and have a negative impact on future cooperation. Therefore, the packaging and transportation link is very important. Let's take a brief look at the matters needing attention in packaging and transportation of thermal transfer film.

2. Thermal transfer film is afraid of moisture and fire
Thermal transfer film is a proud little princess. It is not only afraid of moisture, but also afraid of fire. If the transportation environment is very humid, its life will be in danger. Therefore, remember not to place it in a humid corner.

In addition, thermal transfer film is very easy to burn when encountering open flames. Fire prevention measures must be in place during transportation to avoid contact with flammable substances.

3. Thermal transfer film should be noted when packaging product instructions
When packaging thermal transfer film, all kinds of labels and instructions must be noted. Because thermal transfer film can be divided into more than ten kinds of materials based on the application, product information is noted in the packaging so that customers can quickly understand the detailed information.

This information includes manufacturer, production date, material used, production address, contact number, etc. Proper outer packaging can make customers feel the meticulousness and formality of manufacturers, so that they can use it more assured.

4. Give "preferential treatment" to thermal transfer films during transportation
Before transportation, carefully pack the thermal transfer films. Since the flower films are made of PET film as the base material, the material is relatively soft and easily subjected to friction. In order to avoid contact between it and other hard objects, it is recommended that manufacturers can put a layer of transparent bag on the film. The transparent bag can not only prevent dust, but also reduce the friction between objects.

The transportation distance of flower films can be short or long. Some flower films need to cross mountains and ridges. It is recommended to give "preferential treatment" to these flower films. Roll several layers of bubble pads on the surface of each roll of flower film, and stick transparent tape to fix it, so as to ensure that the flower film arrives in the hands of customers intact.
